6.86 Inch 480x1280 Bar Type Round TFT LCD Sunlight Readable NV3051F1

Brand Name : HOTHMI

Model Number : TFT-H068A1ZAINVKN40

Place of Origin : dongguan,China

MOQ : 2

Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram

Supply Ability : 99999

Delivery Time : 25 days

Product Type : Strip TFT

Display Content : 480x1280 dots

Dimensions (mm) : 67.0x181.3x4.7

Viewport Window Size : 6.86 inch

Product Applications : Instruments, Meters

Backlight brightness : 1000cd/m2

Contact Now

6.86 Inch 480x1280 Sunlight Readable Displays TFT LCD NV3051F1/TFT-H068A1ZAINVKN40

Product parameters


Display Size - 6.86 inch
Effective size (mm) - 60.2208x160.5888
Perspective - Full View
Connection method PIN number - FPC-40PIN
Interface method - LVDS 4L
Working temperature - (-20~70℃)
Supply Voltage - 3.3V
Driver chip model - NV3051F1

General Feature

Item

Standard Value

Unit
Display Size 6.86” -
Number of Pixels 480(H)*3(RGB)* 1280(V) -
Active Area 60.2208(H)* 160.5888(V) mm
Outline Dimension 67.00(H) * 181.30(V) * 4.70(D) <TFT> mm
Viewing Direction FULL O'clock -
TFT Interface LVDS 4L(8Bit/VESA format) -
TFT Driver IC NV3051F1 -

TFT Driver Condition

 VCI=2.8V,IOVCC=1.8V(Typ) V
Backlight White LED/10 PCS/5 series 2 parallel -
Touch Panel Whitout TP -
CTP Driver IC - - - -
CTP Driver Condition VDD=3.3V(Typ) V
Operation Temperature -20 ～ 70 ℃
Storage Temperature -30 ～ 80 ℃

TFT Pin Description

Pin NO. Symbol Description
1 GND Ground
2 D0P LVDS data Input.
3 D0N LVDS data Input.
4 GND Ground
5 D1P LVDS data Input.
6 D1N LVDS data Input.
7 GND Ground
8 DCKP LVDS clock Input
9 DCKN LVDS clock Input
10 GND Ground
11 D2P LVDS data Input.
12 D2N LVDS data Input.
13 GND Ground
14 D3P LVDS data Input.
15 D3N LVDS data Input.
16～17 GND Ground
18～19 VCI Analog Power(2.6 ~ 3.3 V,2.8V Type)
20～23 NC Open Pin
24 RESX Global reset pin. Active low to enter reset state.
25 STBYB Connector to “Pin 18”
25 NC Open Pin
27 GND Ground
28～29 LEDK Backlight cathode
30 GND Ground
31 NC Open Pin
32～33 GND Ground
34 NC Open Pin
35～36 LEDA Backlight anode
37 GND Ground
38～39 VCI Analog Power(2.6 ~ 3.3 V,2.8V Type)
40 NC Open Pin
